Climate ClassSN、N、ST、T
Temperature Range,℃-10~-86
Total Net Capacity,L190
Number of bottles98
Refrigerantmixed Refrigerant
Voltage/Frequency,V/Hz
220~240/50、220~240/60、110~120/60、100/50(60)
Unit Dimensions(WxDxH)mm1035×750×850
Pack Dimensions(WxDxH)mm1080×780×890
1. Microcomputer control, digital display box temperature, box temperature - 10 ℃ ~ - 86 ℃.
2. High and low temperature alarm control, alarm temperature point can be set as required.
1. Two kinds of alarm system: high and low temperature alarm, sensor fault alarm.
2. Multiple protection functions: start delay, stop interval, extend product service life.
1. Safety lock design to prevent opening at will.
2. Wide voltage design, suitable for use in voltage unstable areas.
3. High quality precoated liner design, drainage holes at the bottom of the box, convenient for cleaning.
1. International famous compressor, fast refrigeration.
2. Thickened insulation layer, super microporous foaming technology, good insulation effect.
3. No fluorine foaming, no fluorine refrigerant, green environmental protection.
4. It adopts single machine auto cascade refrigeration system with compact structure.
The backstage real-time monitoring box temperature, timely arrangement of after-sales service, to avoid economic loss.
At 38 ℃ ambient temperature, the temperature in the box can still reach - 86 ℃, which can meet the user's needs all year round.
